Rittal AX 1039.000 Sheet Steel Compact Enclosure 600 x 380 x 210 mm, IP66

Brand:: Rittal
Part number:: 1039.000
EAN:: 4028177813380

Wide, low IP66 sheet steel wall enclosure, 600 x 380 x 210 mm, with a 550 x 355 mm mounting plate, gland plate and one cam lock. Rittal part number 1039.000.

600 x 380 x 210 mm sheet steel, RAL 7035
IP66, IK10, UL 50E Type 4
550 x 355 mm zinc-plated mounting plate
Single door, 1 cam lock
Gland plate in base, size 4

£98.13 ex VAT£117.76 inc VAT

28 in stock

£98.13 ex VAT£117.76 inc VAT

28 in stock

UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.

Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.

Project quantities or a lead time to check? Request a quote

Specifications

Protection

IP rating	IP66
Impact rating (IK)	IK10
NEMA rating	NEMA 4

Dimensions

Size (W x H x D)	W 600 x H 380 x D 210 mm
Mounting plate (W x H)	550 x 355 mm
Weight	14.274 kg
Rittal gland plate size	Size 4

Construction

Enclosure material	Sheet steel
Door / lid	Plain door
Doors	Single door
Colour	RAL 7035
Lock	Cam lock with 3 mm double-bit insert
Number of locks	1
Hinge can be swapped	Yes
Material thickness	1.25 mm

Fit

Mounting	Surface / wall

What's supplied

Mounting plate included	Yes
Gland plates supplied	1

Identification

Brand	Rittal
Part number	1039.000
EAN	4028177813380
Range	Rittal AX

More technical data

Mounting plate (W x H)	550 x 355 mm, 2.5 mm, zinc-plated
Material	sheet steel; enclosure 1.25 mm, door 1.5 mm
Finish	dipcoat primed, powder-coated outside, textured, RAL 7035
Doors	1; interchangeable door hinge
Locks	1 x cam, 3 mm double-bit insert
Gland plates	1 x size 4, in enclosure base
Protection	IP66, IK10
Weight	14.4 kg
Supply includes	door, mounting plate, gland plate in base, perforated door strip, lock with 3 mm double-bit insert

Same design, other sizes

AX Sheet Steel Compact Enclosure, IP66

Product	Size (W x H x D)	IP rating	Doors	Mounting plate (W x H)	Price ex VAT
1031.000	380 x 300 x 210 mm	IP66	Single door	330 x 275 mm	£69.12
1380.000	380 x 380 x 210 mm	IP66	Single door	330 x 355 mm	£74.14
1038.000	380 x 600 x 210 mm	IP66	Single door	330 x 575 mm	£87.69
1338.000	380 x 600 x 350 mm	IP66	Single door	330 x 575 mm	£146.15
1045.000	400 x 500 x 210 mm	IP66	Single door	350 x 475 mm	£85.94
1037.000	400 x 800 x 300 mm	IP66	Single door	345 x 775 mm	£171.44
1050.000	500 x 500 x 210 mm	IP66	Single door	450 x 475 mm	£105.16
1350.000	500 x 500 x 300 mm	IP66	Single door	450 x 475 mm	£135.69
1057.000	500 x 700 x 250 mm	IP66	Single door	450 x 675 mm	£150.15
1039.000 This product	600 x 380 x 210 mm	IP66	Single door	550 x 355 mm	£98.13
1339.000	600 x 380 x 350 mm	IP66	Single door	550 x 355 mm	£161.34
1060.000	600 x 600 x 210 mm	IP66	Single door	550 x 575 mm	£117.86
1054.000	600 x 600 x 250 mm	IP66	Single door	550 x 575 mm	£148.90
1360.000	600 x 600 x 350 mm	IP66	Single door	550 x 575 mm	£175.72
1076.000	600 x 760 x 210 mm	IP66	Single door	550 x 735 mm	£143.16
1376.000	600 x 760 x 350 mm	IP66	Single door	550 x 735 mm	£207.80
1058.000	600 x 800 x 250 mm	IP66	Single door	545 x 775 mm	£180.88
1059.000	600 x 800 x 400 mm	IP66	Single door	545 x 775 mm	£233.44
1090.000	600 x 1000 x 250 mm	IP66	Single door	545 x 975 mm	£203.82
1091.000	600 x 1000 x 400 mm	IP66	Single door	545 x 975 mm	£282.79

Showing 8 of 39 - see all Wall-Mounted Steel Enclosures

Product details

The Rittal AX 1039.000 is a wide, low IP66 sheet steel compact enclosure of 600 x 380 x 210 mm (W x H x D), for places where height is limited but you need a long mounting plate: 550 x 355 mm.

Key features

Single door on one cam lock with a 3 mm double-bit insert; interchangeable hinge lets the door open from either side
550 x 355 mm zinc-plated mounting plate (2.5 mm), roughly 0.20 m² of build area
Cable entry through a size 4 gland plate fitted in the base
1.25 mm steel body, 1.5 mm door with an all-round foamed-in PU door seal; IP66 and IK10

Typical applications

Machine-side and conveyor controls, long terminal rows, and panels fitted above doors, benches or trunking where a taller box will not fit. For deeper components, 1339.000 has the same 600 x 380 mm face at 350 mm deep; 1038.000 is the portrait equivalent (380 x 600 x 210 mm). If the site is corrosive or washed down often, look at AX stainless steel or GRP instead.
