Rittal 2730.010 Viewing Window 597 x 377 x 36 mm for AX 600 x 380 mm Enclosures, IP54
- Brand:
- Rittal
- Part number:
- 2730.010
- EAN:
- 4028177938465
Aluminium-framed acrylic viewing window, 597 x 377 x 36 mm (W x H x D), for AX enclosures 600 x 380 mm, rated IP54. Rittal part number 2730.010.
- For AX enclosures 600 x 380 mm (W x H)
- Visible area 537 x 317 mm
- 36 mm deep, up to 32 mm build depth
- Anodised aluminium frame, acrylic glazing
- IP54 to IEC 60529
1 in stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Protection
| IP rating | IP54 |
|---|
Dimensions
| Weight | 2.6 kg |
|---|
Construction
| Material | Aluminium |
|---|
Fit
| Fits enclosure family | Rittal AX sheet steel, Rittal AX stainless steel, Rittal AX IT |
|---|---|
| Fits enclosure width | 600 mm |
| Fits enclosure height | 380 mm |
What's supplied
| Pack quantity | Single item |
|---|
Identification
| Brand | Rittal |
|---|---|
| Part number | 2730.010 |
| EAN | 4028177938465 |
| Range | Rittal AX |
| Type | Viewing window |
More technical data
| Dimensions (W x H x D) | 597 x 377 x 36 mm |
|---|---|
| Visible area (W x H) | 537 x 317 mm |
| Build depth for components (max.) | 32 mm |
| Design | 30 section |
| Frame | aluminium, natural anodised |
| Glazing | acrylic |
| Supply includes | plastic handle with lock insert no. 3524 E |
| To fit | AX enclosures, width 600 mm, height 380 mm |
Product details
A viewing window for AX enclosures 600 mm wide and 380 mm high, measuring 597 x 377 x 36 mm (W x H x D) with a visible area of 537 x 317 mm. A natural anodised aluminium frame holds an acrylic panel, so displays, meters and indicators stay in view without opening the enclosure. It comes with a plastic handle with lock insert no. 3524 E and is rated IP54.
Key features
- Visible area 537 x 317 mm (W x H)
- Natural anodised aluminium frame with acrylic glazing
- Maximum build depth for components: 32 mm
- Plastic handle with lock insert no. 3524 E included
- IP54 to IEC 60529
Typical applications
Control, distribution and instrumentation enclosures where operators need to check displays, meters, indicator lights or protection relays without opening the enclosure.
Compliance
Protection category IP54 to IEC 60529. Take the window's IP54 rating into account when specifying the protection of the finished enclosure.
Sized for AX enclosures 600 mm wide and 380 mm high. Rittal's accessory lists match it to AX sheet steel enclosures 1039.000 (600 x 380 x 210 mm) and 1339.000 (600 x 380 x 350 mm); AX stainless steel enclosure 1009.000 (600 x 380 x 210 mm); and AX IT enclosure 7641.350 (600 x 380 x 350 mm). Where components need more than 32 mm build depth, the 62 mm deep version, 2760.010, has the same visible area and allows up to 58 mm. For a panel that carries operating devices instead, see operating panel 2744.010.
