Rittal AX 1434.000 GRP Compact Enclosure 300 x 400 x 200 mm, IP66
- Brand:
- Rittal
- Part number:
- 1434.000
- EAN:
- 4028177006409
GRP compact enclosure, 300 x 400 x 200 mm (W x H x D), IP66 and IK09, supplied with a 205 x 325 mm zinc-plated steel mounting plate and two 3 mm double-bit locks. Rittal part number 1434.000.
- 300 x 400 x 200 mm GRP, IP66 and IK09
- 205 x 325 mm steel mounting plate supplied
- Two 3 mm double-bit locks, 130° door opening
- Protection class II, corrosion-resistant GRP
- UL 50E Type 4X and 12, F1 outdoor rating to UL 746C
36 in stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Protection
| IP rating | IP66 |
|---|---|
| Impact rating (IK) | IK09 |
| NEMA rating | NEMA 4X |
Dimensions
| Size (W x H x D) | W 300 x H 400 x D 200 mm |
|---|---|
| Mounting plate (W x H) | 205 x 325 mm |
| Weight | 6.36 kg |
Construction
| Enclosure material | GRP |
|---|---|
| Door / lid | Plain door |
| Doors | Single door |
| Colour | RAL 7035 |
| Lock | Cam lock with 3 mm double-bit insert |
| Number of locks | 2 |
| Hinge can be swapped | Yes |
Fit
| Mounting | Surface / wall |
|---|
What's supplied
| Mounting plate included | Yes |
|---|
Identification
| Brand | Rittal |
|---|---|
| Part number | 1434.000 |
| EAN | 4028177006409 |
| Range | Rittal AX |
More technical data
| Mounting plate (W x H) | 205 x 325 mm, 2.5 mm sheet steel, zinc-plated |
|---|---|
| Enclosure and door | fibreglass-reinforced unsaturated polyester, dyed, no after-treatment; halogen free |
| Colour | similar to RAL 7035 |
| Door | without viewing window, hinged right (changeable to left), opens 130° |
| Locks | 2 x 3 mm double-bit |
| Interior fixing | 25 mm pitch via the universal bracket; interior installation screws required |
| Protection class | II (at 1000 V AC); impact protection IK09 |
| Weight | 6.3 kg |
Product details
The Rittal AX 1434.000 is a GRP compact enclosure of 300 x 400 x 200 mm (W x H x D), rated IP66 and IK09, for small control and terminal duties in corrosive or outdoor locations. Compared with the 250 x 350 mm 1432.000 it gains 50 mm of depth, a 205 x 325 mm mounting plate and a second door lock.
Key features
- Two 3 mm double-bit locks; door hinged on the right, changeable to the left
- 205 x 325 mm zinc-plated steel mounting plate, 2.5 mm thick, supplied
- Non-conductive GRP: protection class II at 1000 V AC, corrosion resistant
- Twin top and bottom door seal doubles as a rain strip, backing up the foamed-in PU seal
Typical applications
A practical size for a small motor starter or relay control circuit, instrument and sensor terminations, or a control point for irrigation, drainage or ventilation equipment, with the extra depth easing cable bending. Where it will face long-term sun and rain, Rittal recommends a PUR paint finish to keep the surface from weathering visually. The hazardous-area version of this size is 9203.100.
Compliance
IP66 to IEC 60529. Type 1, 3R, 3RX, 4, 4X and 12 to UL 50E; NEMA 1, 3R, 3RX, 4, 4X and 12. Meets the F1 outdoor rating to UL 746C. Fire protection corresponding to UL 94-V0.
Genuine Rittal product. Add it to your cart, or ask us about project quantities.
