Rittal AX 6315.450 Steel Operating Housing with Handle Strips 500 x 500 x 210 mm, Front Access
- Brand:
- Rittal
- Part number:
- 6315.450
- EAN:
- 4028177923201
Sheet-steel operating housing with handle strips, 500 x 500 x 210 mm (W x H x D), machinable 3 mm aluminium front, servicing access from the front. Rittal part number 6315.450.
- 500 x 500 x 210 mm operating housing
- Machinable 3 mm aluminium front panel
- Servicing access from the front
- Ø 130 mm support arm connection
- Matching mounting panel 5051.375
6 in stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Protection
| IP rating | IP55 |
|---|---|
| Impact rating (IK) | IK08 |
| NEMA rating | NEMA 12 |
Dimensions
| Size (W x H x D) | W 500 x H 500 x D 210 mm |
|---|---|
| Weight | 13 kg |
Construction
| Enclosure material | Sheet steel |
|---|---|
| Door / lid | Front panel |
| Servicing access | Front |
| Housing type | Handle-strip housing |
| Colour | RAL 7035 |
| Lock | Cam lock with 3 mm double-bit insert |
Fit
| Mounting | Support arm |
|---|
What's supplied
| Mounting plate included | No |
|---|
Identification
| Brand | Rittal |
|---|---|
| Part number | 6315.450 |
| EAN | 4028177923201 |
| Range | Rittal AX |
More technical data
| Enclosure and door | sheet steel, dipcoat primed, powder-coated on the outside, textured paint, RAL 7035 |
|---|---|
| Door seal | all-round foamed-in PU |
| Front panel | 3 mm aluminium, natural anodised, easily machinable |
| Handle strips | natural anodised, with plastic cover caps similar to RAL 7024 |
| Servicing access | from the front |
| Support arm connection | Ø 130 mm cut-out with reinforcement |
| Impact protection | IK08 |
| Matching mounting panel (not included) | Rittal 5051.375 with dispatch bag 5051.300 |
Product details
The Rittal AX 6315.450 is a sheet-steel operating housing with side handle strips, 500 x 500 x 210 mm (W x H x D), with servicing access from the front and a Ø 130 mm support arm connection. Its 500 mm square front takes a mid-size operator panel plus a full set of control and signalling devices.
Key features
- 500 x 500 mm housing front, cut out to the maximum and covered by an easily machinable 3 mm aluminium panel
- Ø 130 mm support arm connection with reinforcement; an off-centre position is preformed and easily drilled out
- Cam lock with 3 mm double-bit insert, exchangeable for 27 mm lock inserts, type A
- Rotate the housing to swap the support arm connection and door hinge sides
- Integral interior installation bracket with system punchings
Typical applications
Main operator stations for production machines, test rigs and process skids, where an HMI, emergency stop, key switches and indicator lamps share one front. Check the support arm system's load rating against the fitted weight. The rear-access version of this size is 6320.450.
Compliance
Type 1 and 12 to UL 50E; NEMA 1 and 12.
