Illustration - our own render; see the datasheet for exact details.
Rittal AX 9203.100 ATEX GRP Enclosure 300 x 400 x 200 mm, IP65, Zones 1/2 or 21/22
- Brand:
- Rittal
- Part number:
- 9203.100
- EAN:
- 4028177952072
GRP enclosure for hazardous areas (Zones 1/2 or 21/22), 300 x 400 x 200 mm (W x H x D), IP65 and IK09, with two locks and a 205 x 325 mm mounting plate. Rittal part number 9203.100.
- For Zones 1/2 or 21/22 to ATEX 2014/34/EU
- ATEX and IECEx component certificates (U)
- 300 x 400 x 200 mm GRP, IP65 and IK09
- Two locks, 205 x 325 mm mounting plate
- Ex e and Ex tb to EN 60079
Out of stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Protection
| IP rating | IP65 |
|---|---|
| Impact rating (IK) | IK09 |
| NEMA rating | NEMA 4X |
| Ex zone | Zones 1/2 and 21/22 (ATEX) |
| Operating temperature | −40 to +70 °C |
Dimensions
| Size (W x H x D) | W 300 x H 400 x D 200 mm |
|---|---|
| Mounting plate (W x H) | 205 x 325 mm |
| Weight | 7.1 kg |
Construction
| Enclosure material | GRP |
|---|---|
| Door / lid | Plain door |
| Doors | Single door |
| Colour | RAL 9011 |
| Lock | Cam lock with 3 mm double-bit insert |
| Number of locks | 2 |
Fit
| Mounting | Surface / wall |
|---|
What's supplied
| Mounting plate included | Yes |
|---|
Identification
| Brand | Rittal |
|---|---|
| Part number | 9203.100 |
| EAN | 4028177952072 |
| Range | Rittal AX Ex |
More technical data
| Mounting plate (W x H) | 205 x 325 mm, 2.5 mm sheet steel, zinc-plated |
|---|---|
| Enclosure and door | fibreglass-reinforced unsaturated polyester, surface resistance < 10⁹ Ω |
| Door seal | bonded, all-round silicone |
| Supplied as | enclosure, door and mounting plate |
| Ambient temperature | -40 °C to +70 °C (may be limited by the installed equipment) |
| Impact protection | IK09 |
Product details
The Rittal AX 9203.100 is a 300 x 400 x 200 mm (W x H x D) GRP enclosure for hazardous areas, rated IP65 and IK09, for Zones 1/2 or 21/22 to ATEX 2014/34/EU. Against the 250 x 350 mm 9202.100 it adds 50 mm of depth, a 205 x 325 mm mounting plate and a second lock.
Key features
- Two locks and a 205 x 325 mm zinc-plated steel mounting plate, 2.5 mm thick
- ATEX and IECEx component certificates
- Surface resistance below 10⁹ Ω, specified to limit electrostatic charging
- Bonded all-round silicone door seal
Typical applications
Suits Ex e terminal boxes with more circuits, local control stations, and junction points on skids, tank farms, loading bays and solvent stores, where the extra depth helps with terminals and cable bending. The standard (non-Ex) AX GRP enclosure of the same size is 1434.000.
Compliance
Zones 1 and 2 (gas) or 21 and 22 (dust) to ATEX 2014/34/EU. Types of protection to EN 60079: increased safety (Ex e) and protection by enclosure (Ex tb). Component certificates PTB 03 ATEX 1011U and IECEx PTB 10.0011U: 'U' denotes a component certificate, covering the enclosure as supplied, not finished equipment. Whoever builds the finished assembly, including its installed equipment, cable entries and any machining, must have it assessed and certified for its application. IP65 to IEC 60529; NEMA Type 1, 3R, 3RX, 4, 4X and 12.
Genuine Rittal product. Add it to your cart, or ask us about project quantities.
