Europa LBF4003PSNME 400A 3-Pole + Switched Neutral IP65 Steel Enclosed BS88 Switch Fuse
- Brand:
- Europa Components
- Part number:
- LBF4003PSNME
- EAN:
- 5056551210370
Europa LBF4003PSNME: a 400 A 3-pole + switched neutral enclosed BS88 switch fuse in an IP65 steel enclosure, with a door-interlocked, padlockable handle. Isolation and fuse protection for a sub-main or major plant item in one unit.
- 400 A rated, 3-pole + switched neutral
- BS88 (HRC) fuse carriers built in
- Door-interlocked steel enclosure, IP65
- Padlockable handle for safe lock-off
- Genuine Europa Components product
Out of stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 2-3 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Rated current | 400 A |
|---|---|
| Poles / neutral | 3 pole + switched neutralWhat does this mean?Three phase poles plus a dedicated neutral pole, all worked by the one handle, so the neutral is isolated together with the phases. |
| Supply | Three phase |
| Utilisation category | AC-23 |
| Current at AC-23 | 400 A |
| Fuse type | BS88 |
Protection
| Door interlock | Yes |
|---|---|
| IP rating | IP65 |
Construction
| Enclosure material | Sheet steel |
|---|
Fit
| Mounting | Surface / wall |
|---|
What's supplied
| Fuses supplied | Yes |
|---|
Identification
| Brand | Europa Components |
|---|---|
| Part number | LBF4003PSNME |
| EAN | 5056551210370 |
| Range | Europa LBF |
| Type | Switch fuse |
More technical data
| Utilisation category | AC-23 at 400 V (415 V) |
|---|---|
| Enclosure | steel, IP65 |
| Fuse type | BS88 (HRC) fuse links |
Product details
The Europa LBF4003PSNME is a 400 A IP65 steel enclosed switch fuse for a sub-main or major plant item. A door-interlocked load-break switch and a set of BS88 fuse carriers share one housing, so the circuit is isolated and fused at the same point.
Key features
- 400 A three-pole switch-disconnector with a switched neutral pole, so the circuit is isolated in one action
- BS88 fuse carriers built in: overcurrent and short-circuit protection without a separate fuse box
- Door-interlocked enclosure - the door will not open with the switch in the ON position, keeping hands away from live fuse contacts
- Padlockable handle for safe isolation and lock-off during maintenance
- Steel enclosure rated IP65 - dust-tight and protected against water jets - for indoor industrial environments
- Defeat mechanism lets authorised personnel open the door with the switch on where testing demands it
Typical applications
Applications include feeding a sub-distribution board, a motor control centre, a large chiller or pump house, a section of a production line, or a temporary site supply. It is the device that lets a whole downstream section be dropped and locked off for maintenance while the fuses carry the short-circuit duty.
Compliance
Europa's LBF enclosed switch fuses are declared to EN 60947-1 and EN 60947-3, the standards covering low-voltage switchgear and switch-disconnectors. IP65 means dust-tight and protected against water jets. Europa specifies the steel-enclosed units for indoor use and states that they are not suitable for outdoor or external applications - choose the GRP version where the environment is harsher.
