Terasaki TRP250NL Neutral Link for 250AF 3-Pole Incomer, for Resilience Plus Panelboards
- Brand:
- Terasaki
- Part number:
- TRP250NL
Neutral link for a 3-pole 250AF incomer in the TRP250INC housing of a Resilience Plus 400 A panel board. Terasaki part number TRP250NL.
- For a 3-pole 250AF incomer
- Fits the TRP250INC incomer housing
- Resilience Plus 400 A boards
- Not needed with a 4-pole incomer
Available to order
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Rated current | 250 A |
|---|
Fit
| Panelboard range | Resilience PlusWhat does this mean?Modular: a separate incomer housing beside the panel board, with add-on enclosures and cableways. 400 A or 800 A busbars, 6 to 18 outgoing ways, outgoing MCCBs up to 250 A (400 A on the twin board), Form 3a or 3b Type 2, doors optional. |
|---|
Identification
| Brand | Terasaki |
|---|---|
| Part number | TRP250NL |
| Range | Terasaki Resilience |
| Type | Neutral link |
More technical data
| Part type | neutral link for a 3-pole incomer |
|---|---|
| Frame | 250AF; rating 250 A |
| Housing | TRP250INC (Resilience Plus 400 A boards) |
| Board busbars | certified, 36 kA for 1 s |
Product details
The Terasaki TRP250NL is the 250AF neutral link for Resilience Plus, fitted in the TRP250INC incomer housing when the incoming device is 3-pole. A 3-pole MCCB or switch-disconnector has no neutral pole, so this link provides the neutral connection for the board; with a 4-pole device it is not needed.
Key features
- For a 3-pole 250AF incomer in the TRP250INC housing
- Rated 250 A
- Suits a 3-pole S250-SJ MCCB or S250-SN switch-disconnector
- Not needed with a 4-pole incomer
Typical applications
Resilience Plus 400 A boards fed through the 250 A incomer housing with a 3-pole TemBreak 2 Lite device, for example a sub-main serving a floor or a tenant area. Order the link with the housing and the device so the incomer is complete.
Compliance
Compliance belongs to the assembled board: Terasaki states that Resilience Plus 400 A panel boards meet the requirements of BS EN 61439-2, with certified busbars rated 36 kA for 1 s.
What it fits: The TRP250INC incomer housing on any Resilience Plus 400 A board, with a 3-pole TemBreak 2 Lite device: S250-SJ MCCB 930683 (160 A), 930690 (200 A) or 930706 (250 A), or S250-SN switch-disconnector 930942 (250 A). The 800AF and 1250AF housings use TRPDHNL and TRPHXNL.
Add it to your cart with the housing and device, or plan the whole incomer in our Panel Builder.
