Europa SPSF100M-F 100A 5-Module Metal Clad IP54 Fused Switch with Fuses
- Brand:
- Europa Components
- Part number:
- SPSF100M-F
- EAN:
- 5056551217058
Europa SPSF100M-F 100 A metal-clad fused switch in a five-module IP54 enclosure, 160 x 240 x 100 mm. Supplied with 63 A, 80 A and 100 A fuses.
- 100 A rated fused switch
- Metal clad enclosure, IP54
- 5 module, 160 x 240 x 100 mm
- Supplied with 63 A, 80 A and 100 A fuses
Out of stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 2-3 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Rated current | 100 A |
|---|
Protection
| Door interlock | No |
|---|---|
| IP rating | IP54 |
Dimensions
| Size (W x H x D) | W 160 x H 240 x D 100 mm |
|---|
Construction
| Enclosure material | Sheet steel |
|---|---|
| Enclosure style | Metal clad |
What's supplied
| Fuses supplied | Yes |
|---|
Identification
| Brand | Europa Components |
|---|---|
| Part number | SPSF100M-F |
| EAN | 5056551217058 |
| Range | Europa SPSF |
| Type | Switch fuse |
More technical data
| Enclosure | metal clad, IP54 |
|---|---|
| Format | 5 module |
| Fuses | supplied with 1 x 63 A, 1 x 80 A and 1 x 100 A |
Product details
The Europa SPSF100M-F is a 100 A metal-clad fused switch in a five-module IP54 enclosure measuring 160 mm wide by 240 mm high by 100 mm deep. It gives a distribution or sub-circuit a compact, wall-mounted switched fuse unit where a full enclosed switch fuse would be oversized.
Key features
- 100 A rated fused switch in a compact five-module format
- Metal-clad enclosure rated IP54: protected against dust ingress and splashing water
- Wall-mountable at 160 x 240 x 100 mm (W x H x D), so it fits where a larger enclosed switch fuse will not
- Switching and fuse protection in one unit, saving a separate isolator and fuse carrier
- Supplied with one 63 A, one 80 A and one 100 A fuse, so the protective rating can be chosen on site
Typical applications
A compact fused switch like this is used as a service or sub-main switch: the head of a small distribution board, an incoming switch for a garage, workshop or outbuilding, a submeter position, or a switched fuse ahead of a consumer unit. It suits jobs where a 100 A fused isolator is needed but the space available is a small panel or a run of surface trunking rather than a switch room.
