Europa FS1003PSNME 100A 3-Pole + Switched Neutral Door-Interlocked Fused Switch, Steel Enclosure
- Brand:
- Europa Components
- Part number:
- FS1003PSNME
- EAN:
- 5056551205994
Europa FS1003PSNME 100 A three-pole and switched-neutral enclosed fused switch with a door-interlocked steel enclosure and gG/gL fuse carriers. Local isolation and overcurrent protection for a machine or sub-circuit.
- 100 A, 3-pole + switched neutral
- gG/gL fuse carriers to EN 60269
- Door-interlocked steel enclosure
- 690 V rated, 6 kV impulse withstand
- 30 kA rated fused short-circuit current
Out of stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 2-3 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Rated current | 100 A |
|---|---|
| Poles / neutral | 3 pole + switched neutralWhat does this mean?Three phase poles plus a dedicated neutral pole, all worked by the one handle, so the neutral is isolated together with the phases. |
| Supply | Three phase |
| Utilisation category | AC-22 |
| Current at AC-22 | 100 A |
| Fuse type | gG/gL (EN 60269) |
Protection
| Door interlock | Yes |
|---|---|
| IP rating | IP65 |
Construction
| Enclosure material | Sheet steel |
|---|
Fit
| Mounting | Surface / wall |
|---|
Identification
| Brand | Europa Components |
|---|---|
| Part number | FS1003PSNME |
| EAN | 5056551205994 |
| Range | Europa FS |
| Type | Switch fuse |
More technical data
| Utilisation | AC-22 at 400 V (415 V) |
|---|---|
| Rated operational voltage Ue | 690 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Rated fused short-circuit current | 30 kA |
| Fuse links | gG/gL type to EN 60269-1 / HD 60269-2 |
| Enclosure | steel, door-interlocked |
| Terminal capacity | 2.5-35 mm² solid or stranded; 4-35 mm² fine strand with ferrule; 2.5 Nm torque |
Product details
The Europa FS1003PSNME is a 100 A three-pole and switched-neutral enclosed fused switch: a load-break switch and gG/gL fuse carriers in one door-interlocked steel enclosure. It gives a machine or sub-circuit a lockable point of isolation and its own overcurrent protection, ready to mount on the wall or beside the plant.
Key features
- 100 A rated, three-pole with a switched neutral so all four conductors are broken
- Integral fuse carriers for gG/gL fuse links to EN 60269 - short-circuit and overload protection without a separate fuse unit
- Door interlock prevents the enclosure being opened with the switch in the ON position
- 30 kA rated fused short-circuit current, so it can be used where prospective fault current is high
- Rated to 690 V, giving headroom on 400/415 V three-phase systems
- Steel enclosure for robust wall mounting in industrial environments
Typical applications
Fused switches at this size are fitted as local isolators and protection for individual machines and small sub-circuits: a motor or pump, a compressor, an extract fan, a packaging or conveyor drive, a small machine cell, or a supply to an outbuilding. Mounted within sight of the equipment, the switch gives the maintenance electrician a lockable means of isolation while the fuses provide the circuit's short-circuit protection.
Compliance
The switch is built to IEC and EN 60947-3 for low-voltage switch-disconnectors, and the fuse holders to EN 60269-1 / HD 60269-2. Rated at 690 V with a 6 kV impulse withstand and a 30 kA rated fused short-circuit current, it suits 400/415 V industrial systems.
