Europa 400x500x175mm IP65 Insulated ABS Enclosure, Clear Polycarbonate Door
- Brand:
- Europa Components
- Part number:
- PBE504017C
- EAN:
- 5056551214019
Europa IP65 insulated ABS enclosure, 400 x 500 x 175 mm, with a hinged clear polycarbonate door. The window lets you read meters and check breaker positions without opening the enclosure. Back plate and fixing brackets included.
- IP65 dust-tight, jet-proof insulated ABS
- 400 x 500 x 175 mm external (W x H x D)
- Clear polycarbonate door for at-a-glance checks
- Back plate and fixing brackets included
- Non-conductive: no enclosure earth bond
6 in stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 2-3 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Protection
| IP rating | IP65 |
|---|
Dimensions
| Size (W x H x D) | W 400 x H 500 x D 175 mm |
|---|---|
| Mounting plate (W x H) | 340 x 450 mm |
Construction
| Enclosure material | ABS |
|---|---|
| Door / lid | Clear door |
| Doors | Single door |
| Box type | Hinged-door enclosure |
| Colour | RAL 7035 |
Fit
| Mounting | Surface / wall |
|---|
What's supplied
| Mounting plate included | Yes |
|---|
Identification
| Brand | Europa Components |
|---|---|
| Part number | PBE504017C |
| EAN | 5056551214019 |
| Range | Europa PBE |
More technical data
| Internal depth | 145 mm |
|---|---|
| Mounting plate | 450 x 340 mm (H x W) |
| Material | ABS, colour light grey RAL 7035 |
| Door | hinged, clear polycarbonate |
| Nominal weight | 4.30 kg |
- Back plate and fixing brackets included
Product details
The Europa 400 x 500 x 175 mm IP65 insulated ABS enclosure with a clear polycarbonate door suits assemblies that get looked at more often than they get opened. Meters, indicator lamps and MCB positions stay visible through the door, so routine checks do not break the seal or expose live parts. The moulded ABS body is non-conductive and free of the corrosion that comes with painted steel. Inside there is room for a wide but shallow layout: broad DIN rail runs, marshalling and terminal work.
Key features
- Hinged clear polycarbonate door: read meters, lamps and breaker positions with the enclosure closed
- IP65: dust-tight and jet-proof, so it copes with washdown and sheltered outdoor positions
- Insulated ABS body - non-conductive, corrosion-free and no earth bond to maintain
- Back plate and fixing brackets supplied, so it is ready to populate and wall mount
- Internal depth of 145 mm, with a 450 x 340 mm mounting plate
Typical applications
At 400 x 500 x 175 mm the usual duties are marshalling and interface panels, instrumentation cabinets, and building services control in risers and plant rooms where depth is restricted. Insulated ABS is the sensible choice indoors and in sheltered positions where a steel enclosure would be heavier, need bonding and eventually corrode.
Compliance
IP65, as defined by the IP code in BS EN 60529, means dust-tight and protected against water jets from any direction: dusty production areas and routine hose-down cleaning. The rating applies to a correctly closed enclosure, so cable entries should be made with glands of an equal or better rating.
Order online today for fast UK dispatch.
