Europa ISPW2323F 32A 110V 2P + E 2-Way IP67 Outlet Splitter
- Brand:
- Europa Components
- Part number:
- ISPW2323F
- EAN:
- 5056551207141
Europa ISPW2323F 2-way outlet splitter, 32A 110V 2P + E, giving 2 IEC 60309 outlets from a single supply. IP67 rated, giving a dust-tight body that also withstands the effects of temporary immersion in water, which suits exposed outdoor, wet and dusty work.
- 32A 110V 2P + E (3-pin) IEC 60309
- IP67 - dust-tight and watertight
- Yellow coded for the 100-130V band
- 2 outlets of the same rating from one supply
- Genuine Europa Components product
48 in stock
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 2-3 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Rated current | 32 A |
|---|---|
| Supply | Single phase |
| Voltage / colour | 110 V yellow |
| Pins | 2P+E (3 pin) |
| Ways | 2-way |
| Earth contact position | 4h |
Protection
| Switched and interlocked | No |
|---|---|
| IP rating | IP67 |
Fit
| Mounting | Cable-mounted |
|---|
Identification
| Brand | Europa Components |
|---|---|
| Part number | ISPW2323F |
| EAN | 5056551207141 |
More technical data
| Voltage | 110V, 100-130V band |
|---|---|
| Configuration | 2P + E (3-pin) |
| Outlets | 2, each 32A 110V 2P + E |
| Colour code | yellow |
| Pattern | IEC 60309 (CEE / commando) |
| Manufacturer | Europa Components, part ISPW2323F |
Product details
Where one 32A 110V supply has to serve more than one load, the Europa ISPW2323F splits it into 2 outlets of identical rating and pin pattern. The 3-pin IEC 60309 body is sealed to dust-tight, watertight IP67, so it can sit on the ground or hang on a stand without losing its protection.
Key features
- Rated 32A at 110V, 2P + E (3-pin), to the IEC 60309 industrial connector pattern
- IP67 dust-tight and watertight rating for exposed outdoor use
- Yellow colour coding for the 100-130V band, so it cannot be mated with a connector from another voltage range
- 2 outlets from one supply, every one to the same 32A 110V pin pattern
- Genuine Europa Components stock item, priced for trade buyers
Typical applications
In practice it is specified for heavier reduced low voltage plant - breakers, cut-off saws, larger site transformers and lighting strings. IP67 takes it outdoors: wet ground, washdown areas, yards, farms and anything left connected through a night of rain. Remember that a splitter multiplies outlets, not capacity: everything drawn across the 2 outlets comes through one 32A supply and the device protecting it, so add up the connected loads first.
Compliance
Europa build this range to the IEC 60309 pattern (BS EN 60309-2 as adopted here), which sets the 3-pin arrangement and the yellow coding for the 100-130V band - the reason kit from different suppliers connects without adaptors. IP67 means a dust-tight body that also withstands the effects of temporary immersion in water. The connector gives no overload or short-circuit protection itself; that stays with the protective device on the circuit feeding it, alongside the RCD protection BS 7671 requires.
