Terasaki's catalogue picture of this product family; see the datasheet for exact details.
Terasaki TRPDHMKME 800AF Incoming MID Meter Mounting Kit, for Resilience Plus Panelboards
- Brand:
- Terasaki
- Part number:
- TRPDHMKME
Incoming meter mounting kit with an MID-approved meter for the Resilience Plus TRPDHINC incomer housing (800AF incoming device). Terasaki part number TRPDHMKME.
- Incoming MID meter mounting kit
- For the TRPDHINC housing, 800AF device
- 400 A and 800 A Resilience Plus boards
- Meter, CT, connections and mounting parts
- MID approved for billing
Available to order
UK delivery £9.95 ex VAT, free on orders of £100 ex VAT or more; usually 3-5 working days.
Minimum order £50 ex VAT. All prices exclude VAT, which is added at checkout.
Project quantities or a lead time to check? Request a quote
Specifications
Electrical
| Frame size | 800 A |
|---|---|
| MID approved | Yes |
Fit
| Panelboard range | Resilience PlusWhat does this mean?Modular: a separate incomer housing beside the panel board, with add-on enclosures and cableways. 400 A or 800 A busbars, 6 to 18 outgoing ways, outgoing MCCBs up to 250 A (400 A on the twin board), Form 3a or 3b Type 2, doors optional. |
|---|
Identification
| Brand | Terasaki |
|---|---|
| Part number | TRPDHMKME |
| Range | Terasaki Resilience |
| Type | Meter mounting kit |
More technical data
| Terasaki part number | TRPDHMKME |
|---|---|
| Product | incoming meter mounting kit, MID |
| Incomer housing | TRPDHINC, 800AF incoming device |
| Boards | Resilience Plus 400 A (400 A max) or 800 A (630 A max) |
| Meter | MID approved |
| Kit contents | meter, CT, connections and mounting parts |
Product details
TRPDHMKME is the MID version of the incoming meter mounting kit for the Resilience Plus TRPDHINC housing, which holds an 800AF incoming device. It fits an MID-approved meter on the incoming supply inside the housing; the kit contains the meter, current transformer (CT), connections and mounting parts, in line with Terasaki's other Resilience meter kits.
Key features
- MID-approved incoming meter for the TRPDHINC housing
- For 400 A boards (up to 400 A) and 800 A boards (up to 630 A from this housing)
- Fitted inside the incomer housing
- Meter, CT, connections and mounting parts included
- Non-MID version: TRPDHMKE
Typical applications
Billing-grade incoming metering on larger Resilience Plus boards: landlord intakes in multi-let buildings, shared plant whose energy is recharged to occupiers, and specifications that call for MID metering at the incomer.
Compliance
The meter is MID approved (Measuring Instruments Directive) for energy readings that are used for billing.
For the TRPDHINC housing on 400 A or 800 A Resilience Plus boards. The 250AF housing uses TRP250MKME and the 1250AF housing TRPHXMKME. In our Panel Builder, MID incoming metering with a TRPDHINC incomer adds this kit.
Add it to your cart, or ask us for help with MID metering on your board.
